Tropical Storm 30Y_01
|
Passive Microwave (PMW) Intensity Information Hurricane Intensity Estimation (HIE) Algorithm Version 9.0 |
Overpass Inten Ring Ring Wind Forecast Final Target
Date Time Score Meaning Pct Diam BTdiff Est Sat Lat Lon Lat Lon Lat Lon
20190218 201627 -930.0 N/A N/A N/A 0.00 30.0 SSMI18 4.3 -161.6 4.3 -161.6 3.6 -161.4 Analysis Plot
20190218 203516 -930.0 N/A N/A N/A 0.00 30.0 SSMI17 4.3 -161.6 4.3 -161.6 4.0 -161.9 Analysis Plot
20190219 032424 -930.0 N/A N/A N/A 0.00 30.0 GMI 4.4 -159.7 4.4 -159.7 4.5 -159.6 Analysis Plot
20190219 081306 -0.9 N/A 1.4% 166.65 .91 30.0 SSMI18 4.4 -158.2 4.4 -158.2 4.2 -158.3 Analysis Plot
20190219 095146 -930.0 N/A N/A N/A 0.00 30.0 SSMI17 4.4 -157.9 4.4 -157.9 5.2 -158.4 Analysis Plot
20190219 200435 N/A N/A N/A N/A N/A 35.0 SSMI18 5.1 -154.8 5.1 -154.8 5.9 -154.9 Analysis Plot
20190220 054603 -4.4 N/A 6.8% 177.76 4.39 45.0 SSMI16 5.0 -153.5 5.0 -153.5 5.5 -153.6 Analysis Plot
20190220 080019 -4.5 N/A 5.5% 188.87 4.48 45.0 SSMI16 4.7 -153.6 4.7 -153.6 5.4 -153.6 Analysis Plot
20190220 080043 -2.3 N/A 65.8% 33.33 2.28 45.0 SSMI17 4.7 -153.6 4.7 -153.6 4.6 -153.2 Analysis Plot
20190220 093834 -930.0 N/A N/A N/A 0.00 45.0 SSMI17 4.9 -153.5 4.9 -153.5 5.5 -153.0 Analysis Plot
20190220 214202 N/A N/A N/A N/A N/A 60.0 SSMI17 6.0 -150.9 6.0 -150.9 6.0 -150.8 Analysis Plot
20190221 055446 8.4 N/A 64.4% 44.44 8.45 65.0 SSMI16 6.4 -149.5 6.8 -149.5 6.8 -149.5 Analysis Plot
20190221 181526 6.2 N/A 52.1% 44.44 6.17 70.0 SSMI15 7.3 -148.1 7.8 -147.9 7.8 -147.9 Analysis Plot
20190221 212914 24.1 >65 kts 27.4% 55.55 24.11 70.0 SSMI17 7.7 -147.6 8.0 -147.5 8.0 -147.5 Analysis Plot
20190222 034735 11.0 N/A 49.3% 22.22 10.99 75.0 AMSR2 8.3 -145.8 8.9 -146.3 8.9 -146.3 Analysis Plot
20190222 111816 15.1 N/A 58.9% 33.33 15.11 75.0 SSMI18 9.4 -145.5 9.5 -145.4 9.5 -145.4 Analysis Plot
20190222 190801 35.3 >65 kts 100.0% 33.33 20.30 80.0 SSMI16 10.0 -144.0 10.3 -144.2 10.3 -144.2 Analysis Plot
20190222 210535 15.2 N/A 49.3% 22.22 15.21 80.0 SSMI18 10.0 -143.8 10.4 -143.9 10.4 -143.9 Analysis Plot
20190223 111436 56.5 >65 kts 100.0% 33.33 41.53 85.0 SSMI17 11.3 -142.7 11.7 -143.0 11.7 -143.0 Analysis Plot
20190223 205325 48.7 >65 kts 100.0% 33.33 33.65 100.0 SSMI18 12.2 -142.3 12.5 -142.4 12.5 -142.4 Analysis Plot
20190223 225457 44.0 >65 kts 100.0% 22.22 29.00 100.0 SSMI17 12.3 -142.2 12.5 -142.1 12.5 -142.1 Analysis Plot
20190224 033716 64.8 >85 kts 100.0% 77.77 49.76 100.0 AMSR2 12.9 -141.7 12.8 -141.7 12.8 -141.7 Analysis Plot
20190224 065719 44.2 >65 kts 100.0% 44.44 29.17 100.0 SSMI16 12.6 -141.4 12.8 -141.5 12.8 -141.5 Analysis Plot
20190224 110124 41.3 >65 kts 100.0% 55.55 26.28 100.0 SSMI17 12.9 -141.2 12.9 -141.4 12.9 -141.4 Analysis Plot
20190224 155201 -930.0 N/A N/A N/A 0.00 95.0 AMSR2 13.2 -140.6 13.2 -140.6 13.4 -141.3 Analysis Plot
20190224 222828 90.2 >85 kts 100.0% 44.44 75.24 95.0 SSMI17 13.2 -140.4 13.3 -140.5 13.3 -140.5 Analysis Plot
20190225 042001 N/A N/A N/A N/A N/A 100.0 AMSR2 13.2 -140.1 13.2 -140.1 13.2 -140.1 Analysis Plot
20190225 064410 85.5 >85 kts 100.0% 44.44 70.48 105.0 SSMI16 13.5 -140.1 13.6 -140.2 13.6 -140.2 Analysis Plot
20190225 090157 81.8 >85 kts 100.0% 44.44 66.80 105.0 SSMI18 13.9 -140.1 13.8 -140.1 13.8 -140.1 Analysis Plot
20190225 105448 84.3 >85 kts 100.0% 44.44 69.28 105.0 SSMI17 14.0 -140.1 13.9 -140.3 13.9 -140.3 Analysis Plot
20190225 142442 96.1 >85 kts 100.0% 55.55 81.07 105.0 GMI 14.2 -140.1 14.3 -140.0 14.3 -140.0 Analysis Plot
20190225 163355 -930.0 N/A N/A N/A 0.00 105.0 AMSR2 14.3 -140.1 14.3 -140.1 15.6 -139.4 Analysis Plot
20190225 200215 66.8 >85 kts 100.0% 55.55 51.75 105.0 SSMI16 14.3 -139.6 14.7 -139.9 14.7 -139.9 Analysis Plot
20190225 221550 67.3 >85 kts 100.0% 44.44 52.26 105.0 SSMI17 14.4 -139.5 14.8 -139.9 14.8 -139.9 Analysis Plot
20190226 063059 80.4 >85 kts 100.0% 44.44 65.45 105.0 SSMI16 15.0 -139.6 15.2 -140.0 15.2 -140.0 Analysis Plot
20190226 085014 70.3 >85 kts 100.0% 44.44 55.25 105.0 SSMI18 15.1 -139.5 15.3 -140.0 15.3 -140.0 Analysis Plot
20190226 194913 46.1 >65 kts 100.0% 33.33 31.11 85.0 SSMI16 15.4 -140.1 15.6 -140.2 15.6 -140.2 Analysis Plot
20190226 221614 44.9 >65 kts 100.0% 44.44 29.88 85.0 SSMI18 15.5 -139.9 15.6 -140.2 15.6 -140.2 Analysis Plot
20190227 040819 41.1 >65 kts 100.0% 33.33 26.06 85.0 AMSR2 16.2 -139.6 16.1 -140.1 16.1 -140.1 Analysis Plot
20190227 061346 15.7 N/A 41.1% 66.66 15.72 85.0 SSMI16 16.2 -139.6 16.2 -139.6 16.2 -140.1 Analysis Plot
20190227 100546 3.0 N/A 38.4% 66.66 2.98 80.0 SSMI18 16.3 -139.9 16.3 -139.9 16.4 -140.1 Analysis Plot
20190227 193511 -0.7 N/A N/A 211.09 .71 50.0 SSMI16 16.5 -138.0 16.5 -138.0 16.8 -137.8 Analysis Plot
20190227 214337 -1.6 N/A N/A 99.99 1.56 50.0 SSMI18 16.8 -137.7 16.8 -137.7 17.2 -137.4 Analysis Plot
20190228 081226 -930.0 N/A N/A N/A 0.00 40.0 SSMI18 17.5 -135.3 17.5 -135.3 18.0 -135.3 Analysis Plot
|
|
Legend: - Date/Time are determined from PMW imagery at Forecast (initial guess) Lat/Lon position. - Positive/Negative Latitude = North/South Hemisphere; Longitude = Western/Eastern Hemisphere. - "Ring Diam" value indicates the estimated surface eyewall diameter in km (the MI eyewall edge diameter minus 10 km). - "Ring Pct" is the percentage of the "ring" (eyewall inner boundary) that is 1) colder than the "hot spot" (warmest eye pixel) in the eye by 20K, or 2) the percentage that is a) colder than 232K and b) colder than the "hot spot" by 10K, whichever is greater. - Values are red if Ring % <= 65, yellow/brown if Ring % <= 85 and green if Ring % > 85. - "Tb diff" is the difference between the "hot spot" (warmest eye pixel) and the warmest pixel on the eyewall. - Intensity score are listed as negative, and not used, when the JTWC or NHC estimated Vmax is <55 kts in order to rule out weak but highly symmetric TCs. - Error messages in intensity scores: -920 is used when the hottest pixel in the eye is <200K, to prevent false positives; -930 means <85% of eyewall has observations/data. |
