Tropical Storm 30Y_05

Passive Microwave (PMW) Intensity Information
Hurricane Intensity Estimation (HIE) Algorithm
Version 9.0


         Overpass     Inten           Ring    Ring          Wind           Forecast        Final        Target
       Date    Time   Score  Meaning   Pct    Diam  BTdiff   Est   Sat    Lat    Lon    Lat    Lon    Lat    Lon
     20190724 044243 -930.0      N/A   N/A     N/A    0.00  30.0  AMSR2  23.3 -136.4   22.4 -136.6   22.4 -136.6 Analysis Plot
     20190724 111924 -930.0      N/A   N/A     N/A    0.00  30.0 SSMI17  23.9 -137.1   23.9 -137.1   23.7 -137.3 Analysis Plot
     20190724 165003 -930.0      N/A   N/A     N/A    0.00  30.0  AMSR2  24.9 -137.4   24.9 -137.4   25.4 -136.6 Analysis Plot
     20190724 194821 -930.0      N/A   N/A     N/A    0.00  30.0 SSMI16  25.3 -137.5   25.3 -137.5   25.6 -137.2 Analysis Plot
     20190724 224603 -930.0      N/A   N/A     N/A    0.00  30.0 SSMI17  25.7 -137.6   25.7 -137.6   26.1 -136.7 Analysis Plot
     20190725 034741   -4.1      N/A  20.5%  88.88    4.10  30.0  AMSR2  26.7 -137.3   26.7 -137.3   26.6 -138.0 Analysis Plot
     20190725 223255   -0.6      N/A   N/A  111.10     .58  30.0 SSMI17  28.6 -136.4   28.6 -136.4   29.4 -137.2 Analysis Plot
     20190726 091828   -2.4      N/A  12.3% 166.65    2.43  35.0 SSMI18  30.9 -135.8   30.9 -135.8   31.4 -136.1 Analysis Plot
     20190726 163551   -1.8      N/A   N/A   55.55    1.76  35.0  AMSR2  32.9 -135.4   32.9 -135.4   33.1 -135.7 Analysis Plot
     20190726 210303   -2.1      N/A   5.5% 111.10    2.06  35.0 SSMI16  33.7 -135.9   33.7 -135.9   34.0 -135.9 Analysis Plot
     20190727 033752    N/A      N/A   N/A     N/A     N/A  35.0  AMSR2  35.0 -136.7   35.0 -136.7   35.2 -136.6 Analysis Plot
     20190727 084056 -930.0      N/A   N/A     N/A    0.00  35.0 SSMI18  35.3 -137.5   35.3 -137.5   35.4 -138.3 Analysis Plot
     20190727 100517    N/A      N/A   N/A     N/A     N/A  35.0 SSMI17  35.3 -137.7   35.3 -137.7   35.3 -138.3 Analysis Plot


Legend:

  - Date/Time are determined from PMW imagery at Forecast (initial guess) Lat/Lon position.

  - Positive/Negative Latitude = North/South Hemisphere; Longitude = Western/Eastern Hemisphere.

  - "Ring Diam" value indicates the estimated surface eyewall diameter in km (the MI eyewall edge diameter minus 10 km).

  - "Ring Pct" is the percentage of the "ring" (eyewall inner boundary) that is 1) colder than the "hot spot" (warmest eye pixel) in the eye by 20K, or 2) the percentage that is a) colder than 232K and b) colder than the "hot spot" by 10K, whichever is greater.
  - Values are red if Ring % <= 65, yellow/brown if Ring % <= 85 and green if Ring % > 85.

  - "Tb diff" is the difference between the "hot spot" (warmest eye pixel) and the warmest pixel on the eyewall.

  - Intensity score are listed as negative, and not used, when the JTWC or NHC estimated Vmax is <55 kts in order to rule out weak but highly symmetric TCs.

  - Error messages in intensity scores: -920 is used when the hottest pixel in the eye is <200K, to prevent false positives; -930 means <85% of eyewall has observations/data.
