Geo IR 85-92GHz
Date/Time_(UTC) Source Sensor Vmax(kts) ARCHER Lat Lon Geo-ref Lat Lon 50% cert. rad. 95% cert. rad. Eye diam (deg) % cert. of eye
20250415 18:43:44 * SSMIS-16 85-92GHz 52.1 -27.36 171.80 -26.80 171.77 0.49 1.38 1.50 4.8
20250415 15:45:54 SSMIS-18 85-92GHz 50.4 *** *** *** *** *** *** 0.50 ***
20250415 14:11:32 AMSR2 85-92GHz 50.0 *** *** *** *** *** *** 0.10 ***
20250415 07:38:27 GMI 85-92GHz 46.4 -22.04 172.03 -22.37 172.14 0.28 0.80 0.30 32.3
20250415 07:28:07 * SSMIS-16 85-92GHz 46.2 -22.12 172.06 -22.52 172.20 0.26 0.75 0.50 26.4
20250415 04:30:59 * SSMIS-18 85-92GHz 45.0 -20.88 171.47 -21.19 171.70 0.17 0.48 5.00 0.0
20250414 18:55:16 * SSMIS-16 85-92GHz 40.0 -17.74 170.30 -17.46 170.16 0.17 0.48 1.70 4.0
20250414 08:18:27 GMI 85-92GHz 36.9 *** *** *** *** *** *** 1.90 ***
20250414 07:43:33 * SSMIS-16 85-92GHz 36.4 -14.46 169.28 -14.62 169.28 0.34 0.97 2.20 0.8
20250414 06:34:50 SSMIS-17 85-92GHz 35.0 *** *** *** *** *** *** 2.30 ***
20250414 04:46:37 SSMIS-18 85-92GHz 35.0 *** *** *** *** *** *** 2.30 ***

Key:

Date/Time: UTC time. If this observation is used in the track it is marked with a "*". If it is used for its own 3-hr window, it is put in bold.

Source/sensor: Satellite source of the analyzed image.

Vmax: Maximum winds listed in the forecast center analysis/forecast, *not* ARCHER.

ARCHER lat/lon: Coordinates of the ARCHER algorithm, valid at the time of the observation. If no center fix could be found, then it is "***".

Geo ref lat/lon: Coordinates of the ARCHER algorithm, valid at the time of the *nearest geo image*.

50% cert. rad.: Radius of the circle (in degrees) that defines the area in which the ARCHER center of rotation is 50% certain. The lower the number, the more certain the position.

95% cert. rad.: Radius of the circle (in degrees) that defines the area in which the ARCHER center of rotation is 95% certain.

Eye diam (deg): ARCHER-resolved eye diameter (in degrees). Green: robust, yellow: less certain, red: not robust.

% cert. of eye: Percent certainty that an eye exists in this image, determined by ARCHER. Currently only available for IR and 85-92 GHz imagery.
