Geo IR 85-92GHz
Date/Time_(UTC) Source Sensor Vmax(kts) ARCHER Lat Lon Geo-ref Lat Lon 50% cert. rad. 95% cert. rad. Eye diam (deg) % cert. of eye
20241004 04:09:00 * Metop-A ASCAT 26.0 -14.48 68.51 -14.57 68.35 0.19 0.54 *** ***
20241004 01:39:31 * SSMIS-16 85-92GHz 27.4 -14.89 68.29 -14.96 68.19 0.20 0.58 3.00 0.0
20241003 23:21:37 SSMIS-18 85-92GHz 28.7 -13.61 69.30 -13.62 69.28 0.62 1.75 1.80 0.2
20241003 22:13:55 GMI 85-92GHz 29.3 *** *** *** *** *** *** 1.70 ***
20241003 22:13:55 GMI 37GHz 29.3 -14.11 69.49 -14.22 69.33 0.34 0.96 0.60 ***
20241003 20:55:52 * AMSR2 85-92GHz 30.0 -13.44 69.56 -13.40 69.61 0.31 0.88 2.20 2.6
20241003 20:55:52 AMSR2 37GHz 30.0 -13.89 69.66 -13.85 69.71 0.45 1.27 0.60 ***
20241003 17:03:00 * Metop-A ASCAT 31.2 -12.84 70.05 -12.87 69.98 0.16 0.46 *** ***
20241003 13:09:17 SSMIS-17 85-92GHz 36.1 -12.87 70.95 -12.92 70.66 0.61 1.73 2.80 0.3
20241003 08:27:18 * AMSR2 85-92GHz 41.9 -12.75 71.82 -12.76 71.81 0.44 1.25 1.00 1.9
20241003 08:27:18 AMSR2 37GHz 41.9 -12.85 71.97 -12.86 71.96 0.45 1.27 0.80 ***
20241003 04:30:00 Metop-A ASCAT 45.0 *** *** *** *** *** *** *** ***
20241002 20:12:30 * AMSR2 85-92GHz 45.0 -12.54 73.38 -12.56 73.35 0.18 0.52 0.20 98.1
20241002 20:12:30 AMSR2 37GHz 45.0 -12.49 73.59 -12.51 73.56 0.42 1.18 0.20 ***
20241002 13:23:44 * SSMIS-17 85-92GHz 48.8 -11.64 74.43 -11.74 74.28 0.24 0.68 0.70 55.7
20241002 13:02:21 SSMIS-16 85-92GHz 50.0 -11.73 74.72 -11.86 74.53 0.41 1.16 1.00 14.1
20241002 10:44:42 SSMIS-18 85-92GHz 49.0 -11.62 74.74 -11.75 74.66 0.19 0.55 0.70 85.6
20241002 09:33:55 * GMI 85-92GHz 48.0 -11.28 74.76 -11.05 74.87 0.14 0.40 0.40 100.0
20241002 09:33:55 GMI 37GHz 48.0 -11.13 74.91 -10.90 75.02 0.18 0.50 0.20 ***
20241002 00:46:04 * SSMIS-17 85-92GHz 45.0 -9.99 75.63 -9.95 75.72 0.16 0.45 0.90 80.0
20241001 21:58:56 GMI 85-92GHz 43.3 -9.80 75.71 -9.77 75.81 0.24 0.68 0.60 61.4
20241001 21:58:56 * GMI 37GHz 43.3 -9.85 75.60 -9.82 75.70 0.23 0.66 0.30 ***

Key:

Date/Time: UTC time. If this observation is used in the track it is marked with a "*". If it is used for its own 3-hr window, it is put in bold.

Source/sensor: Satellite source of the analyzed image.

Vmax: Maximum winds listed in the forecast center analysis/forecast, *not* ARCHER.

ARCHER lat/lon: Coordinates of the ARCHER algorithm, valid at the time of the observation. If no center fix could be found, then it is "***".

Geo ref lat/lon: Coordinates of the ARCHER algorithm, valid at the time of the *nearest geo image*.

50% cert. rad.: Radius of the circle (in degrees) that defines the area in which the ARCHER center of rotation is 50% certain. The lower the number, the more certain the position.

95% cert. rad.: Radius of the circle (in degrees) that defines the area in which the ARCHER center of rotation is 95% certain.

Eye diam (deg): ARCHER-resolved eye diameter (in degrees). Green: robust, yellow: less certain, red: not robust.

% cert. of eye: Percent certainty that an eye exists in this image, determined by ARCHER. Currently only available for IR and 85-92 GHz imagery.

Links to related versions: Summary table, ARCHER Track table, ARCHER Track Image Archive, Intensity Estimation, ARCHER-ERC page, F-Decks

This page automatically updates every 5 minutes
