Geo IR 85-92GHz
Date/Time_(UTC) Source Sensor Vmax(kts) ARCHER Lat Lon Geo-ref Lat Lon 50% cert. rad. 95% cert. rad. Eye diam (deg) % cert. of eye
20251013 16:59:55 AMSR2 85-92GHz 35.0 32.15 -57.31 32.11 -57.16 0.43 1.22 0.10 2.3
20251013 16:48:26 GMI 85-92GHz 35.0 32.05 -57.41 32.01 -57.22 0.42 1.17 0.80 2.3
20251013 06:58:27 * GMI 85-92GHz 35.0 32.06 -59.65 32.00 -59.84 0.36 1.02 0.20 5.0
20251013 05:59:06 AMSR2 85-92GHz 35.0 32.16 -59.80 32.15 -59.84 0.44 1.24 0.10 1.7
20251012 22:15:41 * SSMIS-16 85-92GHz 35.7 31.19 -60.77 31.33 -60.59 0.59 1.66 0.50 0.3
20251012 21:20:57 SSMIS-17 85-92GHz 36.1 31.24 -61.17 31.17 -61.23 0.60 1.68 0.10 0.2
20251012 20:06:42 * SSMIS-18 85-92GHz 36.6 30.94 -61.65 31.02 -61.58 0.48 1.35 0.30 0.6
20251012 17:28:27 GMI 85-92GHz 37.7 *** *** *** *** *** *** 0.60 ***
20251012 10:55:53 SSMIS-16 85-92GHz 40.4 30.77 -61.68 30.91 -61.62 0.56 1.58 0.40 0.3
20251012 10:01:15 SSMIS-17 85-92GHz 40.8 30.12 -61.87 29.89 -61.96 0.57 1.61 3.40 0.9
20251012 08:47:04 * SSMIS-18 85-92GHz 41.3 30.15 -61.79 30.14 -61.79 0.42 1.19 4.30 5.5
20251012 07:43:26 * GMI 85-92GHz 41.8 29.91 -62.15 30.09 -62.08 0.46 1.29 3.00 3.6
20251011 22:28:15 * SSMIS-16 85-92GHz 45.0 27.20 -63.44 27.50 -63.38 0.33 0.94 1.50 9.1
20251011 21:34:09 SSMIS-17 85-92GHz 45.0 27.69 -63.71 27.49 -63.75 0.54 1.52 2.50 1.6
20251011 21:32:43 SSMIS-17 85-92GHz 45.0 27.68 -63.71 27.49 -63.75 0.55 1.55 2.50 1.4
20251011 20:19:35 * SSMIS-18 85-92GHz 45.0 27.58 -62.87 27.69 -62.85 0.52 1.47 0.30 0.7
20251011 20:18:54 SSMIS-18 85-92GHz 45.0 27.58 -62.87 27.69 -62.85 0.46 1.29 0.30 1.5
20251011 18:13:26 GMI 85-92GHz 45.0 *** *** *** *** *** *** 2.30 ***
20251011 17:10:54 AMSR2 85-92GHz 45.0 *** *** *** *** *** *** 2.00 ***
20251011 11:11:01 SSMIS-16 85-92GHz 45.7 *** *** *** *** *** *** 0.40 ***
20251011 10:17:02 * SSMIS-17 85-92GHz 46.4 24.50 -63.31 24.89 -63.20 0.52 1.48 0.70 3.1
20251011 09:02:44 SSMIS-18 85-92GHz 47.5 *** *** *** *** *** *** 0.90 ***
20251011 06:14:00 AMSR2 85-92GHz 50.0 *** *** *** *** *** *** 0.40 ***
20251010 22:40:21 SSMIS-16 85-92GHz 48.9 22.43 -62.68 22.66 -62.69 0.60 1.70 3.00 0.7
20251010 21:46:43 * SSMIS-17 85-92GHz 48.1 21.96 -63.08 21.75 -63.04 0.37 1.05 0.30 2.0
20251010 20:31:59 * SSMIS-18 85-92GHz 47.1 21.26 -64.49 21.30 -64.50 0.38 1.07 3.10 14.6
20251010 11:26:14 SSMIS-16 85-92GHz 45.0 20.05 -63.47 20.11 -63.50 0.57 1.61 4.00 0.5
20251010 10:32:27 * SSMIS-17 85-92GHz 45.0 19.49 -63.19 19.72 -63.34 0.53 1.50 4.60 2.2
20251010 07:28:25 GMI 85-92GHz 45.0 19.27 -62.03 19.50 -62.32 0.24 0.68 2.50 47.9
20251010 05:32:23 AMSR2 85-92GHz 45.4 18.12 -62.09 18.15 -62.12 0.51 1.43 0.40 25.7
20251009 22:53:01 SSMIS-16 85-92GHz 50.9 17.83 -60.87 17.95 -61.01 0.59 1.66 3.50 1.7
20251009 21:59:32 * SSMIS-17 85-92GHz 51.7 17.72 -61.10 17.56 -60.91 0.41 1.16 3.10 11.5
20251009 17:20:12 AMSR2 85-92GHz 55.0 16.62 -59.85 16.70 -59.95 0.55 1.54 1.50 2.9
20251009 07:52:15 * SSMIS-18 85-92GHz 55.0 16.19 -57.29 16.20 -57.49 0.42 1.19 3.20 12.8
20251008 18:48:27 GMI 85-92GHz 50.0 14.52 -54.11 14.40 -53.79 0.34 0.98 2.20 5.2
20251008 16:36:40 * AMSR2 85-92GHz 50.0 14.60 -53.37 14.79 -53.76 0.27 0.76 2.60 13.3
20251008 07:13:27 * GMI 85-92GHz 46.0 13.31 -49.77 13.23 -49.31 0.44 1.23 1.50 3.3

Key:

Date/Time: UTC time. If this observation is used in the track it is marked with a "*". If it is used for its own 3-hr window, it is put in bold.

Source/sensor: Satellite source of the analyzed image.

Vmax: Maximum winds listed in the forecast center analysis/forecast, *not* ARCHER.

ARCHER lat/lon: Coordinates of the ARCHER algorithm, valid at the time of the observation. If no center fix could be found, then it is "***".

Geo ref lat/lon: Coordinates of the ARCHER algorithm, valid at the time of the *nearest geo image*.

50% cert. rad.: Radius of the circle (in degrees) that defines the area in which the ARCHER center of rotation is 50% certain. The lower the number, the more certain the position.

95% cert. rad.: Radius of the circle (in degrees) that defines the area in which the ARCHER center of rotation is 95% certain.

Eye diam (deg): ARCHER-resolved eye diameter (in degrees). Green: robust, yellow: less certain, red: not robust.

% cert. of eye: Percent certainty that an eye exists in this image, determined by ARCHER. Currently only available for IR and 85-92 GHz imagery.

Links to related versions: ARCHER Track page

This page automatically updates every 5 minutes
