Geo IR 85-92GHz
Date/Time_(UTC) Source Sensor Vmax(kts) ARCHER Lat Lon Geo-ref Lat Lon 50% cert. rad. 95% cert. rad. Eye diam (deg) % cert. of eye
20251107 08:48:16 * SSMIS-18 85-92GHz 26.7 14.99 104.94 14.97 105.00 0.43 1.22 2.90 1.7
20251106 23:53:46 SSMIS-16 85-92GHz 45.6 *** *** *** *** *** *** 2.40 ***
20251106 23:33:26 * GMI 85-92GHz 47.7 14.51 106.34 14.51 106.35 0.39 1.11 1.70 1.7
20251106 22:46:58 SSMIS-17 85-92GHz 52.4 14.65 106.91 14.71 106.76 0.42 1.20 3.80 1.3
20251106 21:36:49 SSMIS-18 85-92GHz 59.6 *** *** *** *** *** *** 3.10 ***
20251106 18:26:34 AMSR2 85-92GHz 79.0 14.47 107.66 14.38 107.88 0.19 0.55 0.70 1.5
20251106 12:03:26 GMI 85-92GHz 100.0 13.40 108.67 13.37 108.81 0.16 0.44 2.10 4.7
20251106 06:12:25 AMSR2 85-92GHz 110.0 13.26 110.65 13.24 110.83 0.13 0.38 0.30 100.0
20251105 23:01:15 * SSMIS-17 85-92GHz 112.6 13.05 112.42 13.05 112.26 0.11 0.30 0.30 100.0
20251105 20:09:37 * SSMIS-18 85-92GHz 105.4 13.30 113.58 13.30 113.44 0.12 0.33 0.30 100.0
20251105 17:43:40 * AMSR2 85-92GHz 99.5 13.13 114.47 13.12 114.54 0.10 0.28 0.40 100.0
20251105 05:28:50 AMSR2 85-92GHz 79.6 11.75 117.61 11.76 117.60 0.09 0.27 0.30 100.0
20251104 23:23:26 GMI 85-92GHz 74.5 11.45 119.40 11.46 119.38 0.10 0.30 0.30 100.0
20251104 22:41:05 * SSMIS-16 85-92GHz 73.9 11.19 119.50 11.27 119.37 0.10 0.28 0.40 100.0
20251104 20:23:44 SSMIS-18 85-92GHz 72.0 *** *** *** *** *** *** 0.60 ***
20251104 11:48:26 * GMI 85-92GHz 70.0 11.49 121.04 11.48 121.08 0.16 0.46 1.90 90.3
20251104 10:02:52 SSMIS-16 85-92GHz 70.6 *** *** *** *** *** *** 1.30 ***
20251103 10:16:56 * SSMIS-16 85-92GHz 87.1 10.46 126.50 10.52 126.20 0.14 0.41 0.20 69.3
20251102 23:13:27 * GMI 85-92GHz 68.7 10.37 128.90 10.35 128.85 0.10 0.28 0.60 100.0
20251102 19:11:19 SSMIS-18 85-92GHz 62.0 10.97 129.52 10.84 129.25 0.18 0.50 0.90 74.1
20251102 19:11:10 * SSMIS-18 85-92GHz 62.0 10.95 129.53 10.82 129.27 0.12 0.35 1.10 99.7
20251102 17:12:55 * AMSR2 85-92GHz 59.3 10.89 129.85 10.87 129.77 0.14 0.38 0.80 100.0
20251102 11:38:26 * GMI 85-92GHz 54.7 11.30 131.78 11.30 131.82 0.17 0.49 0.40 93.6
20251102 06:33:42 SSMIS-18 85-92GHz 50.0 *** *** *** *** *** *** 0.60 ***
20251102 04:57:28 * AMSR2 85-92GHz 49.1 11.22 133.44 11.24 133.28 0.17 0.48 0.40 100.0
20251101 21:40:58 * SSMIS-16 85-92GHz 43.1 11.01 136.54 10.98 136.80 0.35 0.99 1.90 4.1
20251101 20:36:18 * SSMIS-17 85-92GHz 42.2 10.12 136.53 10.11 136.56 0.33 0.93 2.10 8.7
20251101 19:24:50 SSMIS-18 85-92GHz 41.2 10.91 135.32 10.95 135.10 0.43 1.21 2.10 5.4
20251101 16:30:05 * AMSR2 85-92GHz 37.5 10.82 136.37 10.88 136.22 0.36 1.01 0.40 24.7
20251101 06:46:56 SSMIS-18 85-92GHz 25.0 9.70 137.66 9.62 137.86 0.64 1.80 4.20 0.0
20251101 04:13:53 * AMSR2 85-92GHz 25.0 9.78 138.04 9.87 137.85 0.39 1.09 0.50 26.5

Key:

Date/Time: UTC time. If this observation is used in the track it is marked with a "*". If it is used for its own 3-hr window, it is put in bold.

Source/sensor: Satellite source of the analyzed image.

Vmax: Maximum winds listed in the forecast center analysis/forecast, *not* ARCHER.

ARCHER lat/lon: Coordinates of the ARCHER algorithm, valid at the time of the observation. If no center fix could be found, then it is "***".

Geo ref lat/lon: Coordinates of the ARCHER algorithm, valid at the time of the *nearest geo image*.

50% cert. rad.: Radius of the circle (in degrees) that defines the area in which the ARCHER center of rotation is 50% certain. The lower the number, the more certain the position.

95% cert. rad.: Radius of the circle (in degrees) that defines the area in which the ARCHER center of rotation is 95% certain.

Eye diam (deg): ARCHER-resolved eye diameter (in degrees). Green: robust, yellow: less certain, red: not robust.

% cert. of eye: Percent certainty that an eye exists in this image, determined by ARCHER. Currently only available for IR and 85-92 GHz imagery.

Links to related versions: ARCHER Track page
